Imported high-precision diffusion silicon pressure transmitter water supply treatment equipment pipeline hydraulic oil pressure


2022-08-08: [Chinese Article Link]  Detailed description Product description and use: The PTL516 diffused silicon pressure transducer uses precision cores, sensitive components use silicon diffusion injection processes, forming the Whistlestone Bridge, where resistance resistance is built, when pressure is used in the core, MV signals that are generated and pressure is proportional to the previous state. Import treatment chips, high stability, high accuracy silicon blocking the entire bridge, automatic calibration of specialized integrated circuits, high temperature resistance to heat drift, use 316 stainless steel in the core, resistant to corrosion and high temperature, are converted into a standard telecommunications magnification circuit. Type of product specification Main technical parameters Mass - 0.1 ~ 0 ~ 100 MPa Pressure measuring form table pressure, insulation, negative pressure C CC Compensation temperature - 10 ~ 60 °C Working temperature - 15 ~ 65 °C Aggregation FS 0.25% FS Output Select 4 ~ 20 mA Powered Electricity Voltage 24VDC Survey medium 304, baron rubber-compatible fluids Installation of thread M20*1.5, G1/4, G1/2 etc.


Note: This is a machine translated version of the Chinese news media article. A mature and nuanced reading is suggested.
